All-In-One · Indoor, fixed installation
AiO Poster
Modular LED Poster Display
Vanguard's AiO Poster is an all-in-one digital poster: display, player and Android content system in one slim, freestanding unit. Run stored content, stream, or connect a source. Use one on its own, or link several into one seamless screen.
Ideal for Digital signage, anywhere
Models
Link them
One poster, or one big screen
Posters stand side by side with no gap between them and run as one screen. Five 1.5 mm posters make a true Full HD 1920 × 1080 display at 136″; six 1.8 mm posters make the same resolution at 163″. Other combinations give wider formats, such as 32:9.
Everything built in
A complete signage system
Content, connectivity and sensors ship inside every poster. Power it, load content, and it runs.
Android content system
Upload, schedule and control content on the poster itself. No external player.
Always connected
RJ45, Wi-Fi, a local access-point network and 4G.
Video in and out
HDMI in, HDMI out and USB 3.0, plus an external audio interface.
Built-in sensors
Brightness, temperature and humidity sensing.
Leaning stand
Every poster ships with its stand: unbox, place, power on.
Front service
Modules service from the front. A linked wall keeps running while one poster is serviced.
Wall mount
Hangs on a simple cleat.
Seamless linking
Link posters with no gap into one Full HD screen.
Specifications
Two models
| Specification | 1.5 mm384 × 1080 · 66.4″ tall | 1.8 mm320 × 1080 · 79.7″ tall |
|---|
Panel 5
| Pixel pitch | 1.56 | 1.87 |
|---|---|---|
| Pixel type | SMD | |
| Max brightness | 600 | |
| Environmental rating | Indoor | |
| Deployment | Fixed Installation | |
Dimensions & Weights 8
| Display resolution W (px) | 384 | 320 |
|---|---|---|
| Display resolution H (px) | 1,080 | |
| Display width | 600 mm (23.6 in) | |
| Display height | 1687.5 mm (66.4 in) | 2025 mm (79.7 in) |
| Display depth | 50 mm (2 in) | |
| Aspect ratio | 0.4:1 | 0.3:1 |
| Display weight | 57 kg (125.7 lb) | 61 kg (134.5 lb) |
| Display area | 1.0125 m² (10.9 ft²) | 1.215 m² (13.1 ft²) |
Modules 7
| Module resolution W (px) | 192 | 160 |
|---|---|---|
| Module resolution H (px) | 108 | 90 |
| Module width | 300 mm (11.8 in) | |
| Module height | 168.75 mm (6.6 in) | |
| Modules wide | 2 | |
| Modules tall | 10 | 12 |
| Modules total | 20 | 24 |
Pixel Information 6
| Pixel package | SMD1212 | SMD1515 |
|---|---|---|
| Shader/mask type | - | |
| Pixel density (/m2) | 409,600 | 284,444 |
| Viewing angle H/V | 160° / 160° | |
| LED lifetime (h) | 50,000 | |
| Contrast | 8000:1 | |
Processing 11
| IC driver | ICN1065 | |
|---|---|---|
| Scan rate | 1/48 | 1/45 |
| Processing depth (bit) | 14 | |
| Processing depth range | 8-16 | |
| Refresh rate default | 3,840 | |
| Refresh rate range | 3,840 | |
| Frame rate default | 50 | |
| Frame rate options | 50,60 | |
| Color temp default (K) | 8,500 | |
| Color temp range (K) | 2000-9300 | |
| Color gamut | 1.0 -- 4.0 | |
Power 8
| Bonding Wire | Copper | |
|---|---|---|
| Power common | Anode | |
| Max W / panel | 425.3 | 461.7 |
| Max W / m² | 420 | 380 |
| Avg W / panel | 148.8 | 161.6 |
| Avg W / m² | 147 | 133 |
| Max A/cascade | 10 | |
| Operating voltage | 100-240V AC, 50/60 Hz | |
Environmental 4
| Temp operating | -20°C - +50°C (-4.0°F to 122.0°F) | |
|---|---|---|
| Temp storage | -20°C - +60°C (-4.0°F to 140.0°F) | |
| BTU/hr | 1,450.1 | 1,574.4 |
| Operating humidity | 10% - 90%, non-condensing | |
Details 11
| IP rating | IP30 | |
|---|---|---|
| Cabinet material | Aluminum | |
| Max stacking | N/A | |
| Max hanging | N/A | |
| Rear bolt threading | - | |
| Cabling direction | Vertical | |
| Connector power | C13/C14 | |
| Connector data | RJ45 | |
| Serviceability | Front | |
| Warranty (yrs) | 2 | |
| Warranty available | 5 | |
Certifications 2
| EMC rating | B | |
|---|---|---|
| Certifications | CCC (CN), FCC (USA), ETL (USA), LVD (EU), CE (EU), RoHS (EU), UKCA (UK), CB (EMEA), BIS (India), KC (S.Korea), PSE (Japan) | |
Sizes
Poster-sized, people-height
Both models are 23.6 in wide. The 1.5 mm stands 66.4 in tall; the 1.8 mm, 79.7 in.
To scale, standing on the floor, beside a 1.75 m (5 ft 9 in) person
Add-ons & accessories
Configure it your way
Rolling base
EM: epoxy mask (HOB)
EC: epoxy coating (GOB)
Trim: cosmetic edge protection
Flight cases
-Mag: reduced magnetism
Hydrophobic treatmentApplications
Where it is used
- Retail, lobby, and event digital signage
- Trade-show and pop-up displays that scale with the space
- Reception areas and corridors where a slim profile matters
- Temporary meeting-room screens built from stocked posters
Frequently asked questions
About the AiO Poster
What is the All-In-One AiO Poster?
The AiO Poster is our All-In-One vertical LED display — a freestanding digital poster that ships fully assembled and ready to use, with display, processing, and Android-based content system integrated. Use one as standalone signage, or link several side-by-side into one seamless large-format screen.
What is the All-In-One AiO Poster used for?
The AiO Poster combines advertising, information display, presentation, and event signage into one system. It plays stored content directly, streams video, or connects to external sources — so a single poster serves as self-running signage by day and a live presentation display when connected, covering most business display needs alone.
How simple is content management on the All-In-One AiO Poster?
Very — the AiO Poster runs an Android-based system for uploading, scheduling, and controlling content directly on the display, with no external player, complicated tools, or specialized knowledge required. Staff update messaging the way they'd manage any familiar app, keeping content current without an AV background.
Can you combine multiple All-In-One AiO Posters into one big screen?
Yes — AiO Posters link side-by-side into one seamless display with no gaps between units. Five 1.5mm posters or 6 1.8mm posters together form a true Full HD 1920×1080 screen at 136 or 163 inches diagonal, and other combinations create wider formats and custom aspect ratios like 32:9 for larger visuals.
What are the dimensions and resolution of a single All-In-One AiO Poster?
Each AiO Poster is a slim vertical unit roughly two feet wide, available in two heights 5.5 feet for 1.5mm and 6.6 feet for the 1.8mm version. The 1.5mm poster is 384x1080px, while the 1.8mm poster is 320x1080px. That per-unit resolution is what makes combinations work cleanly — each poster contributes a full-height slice of the assembled image at fine pixel pitch.
How do you set up or position All-In-One AiO Posters?
The AiO Poster arrives ready to use and positions three ways: wall-hung, freestanding on its built-in floor stand, or rolling on optional wheels for repositioning between locations. Setup is placement, power, and content — no assembly, no mounting engineering, no installer required for freestanding use.
Does the All-In-One AiO Poster require assembly?
No — the AiO Poster ships fully assembled and ready to use. Unbox, position, power on, and load content; the poster is operational the day it arrives. For multi-poster displays, units link together on site in a straightforward process without tools or technical staff.
What types of businesses gain the most from All-In-One AiO Posters?
Retail shops, trade shows, offices, malls, airports, hotels, and event venues — anywhere lively digital messaging must grab attention in a footprint no bigger than a traditional poster stand. The rolling option adds value for venues that reposition displays by event, season, or promotion.
What warranty and service come with the All-In-One AiO Poster?
The AiO Poster includes a 2-year warranty, extendable to 5 years, with spare parts included. Front-serviceable modules keep the rare repair quick and onsite — and because each poster is self-contained, a multi-poster wall keeps operating while any single unit is serviced.
Can I start with one poster and add more later?
Yes. Posters attach seamlessly to one another, so a single sign can grow into a full display as needs change.
Is it portable?
On the optional rolling base, posters move between rooms without tools.
